FAST MOVER TOOLS, FT1010 AIR PALM SANDER WITH DUST EXTRACTION, 3MM ORBIT, 150MM

Key Features: Pad Diameter 6”/150mm Orbit 3 or 5mm Pad Thread Size 5/16” Free Speed 10,000RPM Minimum Pad Speed 12,000RPM Operating Pressure 90Psi/6.3BAR Air Consumption 12CFM Air Inlet 1/4” BSP Vibration Level (ahd) 9.59*m/s 2 Noise Level 86dB(A) Weight 948g Length 225mm Dscription: FT1010 Instruction Manual Familiarise Yourself with the Controls 1: The throttle is pressure sensitive. Applying pressure will increase rotational speed. 2: Removal of all pressure will stop the machine. 3: our tool comes with a Regulator, make sure that this is in the off position when not in use or to prevent unintentional starts 4: Never leave the tool unattended and connected to the power supply. During Use 1. When using the sander for long periods of time, check the sanding disc for wear. 2. Replace worn discs as worn or clogged discs will make the sander inefficient. 3. The sanding operation will cause heat. Check the material that is being worked on that it is not getting too hot. If this is occurring, stop sanding to allow the material to cool down. 4.You can adjust the speed of the tool by adjusting the pressure you apply to the throttle. 5. Make regular checks on the sanding pad for wear and damage and replace them immediately. 6 Due to the potential heat caused by the sanding process, keep flammable liquids and gases well away from the work area. We recommend that your air tool is connected to the main airline in the way displayed in Fig. 2. 1: Air Tool 2: Whip Hose/Leader Hose 3: Air Fitting 4: Quick Coupling 5: Main Air Hose
